ESG Family Signal Generators Hardkey and Softkey Reference
Recall
User’s Guide 4-87
Delete Seq[n] Reg[nn]
Press this softkey to delete the contents of a specified register in a
specified sequence. Do not press this softkey until you have selected the
correct sequence and register using the
Select Seq and Recall Reg
softkeys. For example, if you want to delete the contents of register 5 in
sequence 4, press
Select Seq. The currently selected sequence is
displayed in the active entry area. Change the number to 4 using the up
and down arrow keys, the front panel knob, or enter a 4 using the
numeric keypad and press the
Enter terminator softkey. Sequence 4 is
now displayed in all softkeys which specify a sequence in this menu.
Now select register 5. (Remember, you must first have saved an
instrument state to this register in sequence 4.) Press
Recall Reg. The
recall register number becomes the active function. Enter the number 5
using the numeric keypad and press the
Enter terminator softkey. The
instrument state is restored from this register and register 5 is now
displayed in all softkeys which specify a register number in this menu.
Now press
Delete Seq [4] Reg[05] and register 5, stored in sequence 4, will
be deleted. The instrument state that you had recalled from this
register remains, however, until you change it. If you deleted this
register in error, you can immediately resave it using the
Save Seq[n] Reg[n] softkey in the Save menu.
NOTE This softkey has exactly the same function as the softkey with the
identical name in the front panel Save key menu.
Softkey Location:
Recall > Delete Seq[n] Reg[nn]
Recall Reg
Press this softkey to recall an instrument state from a saved register.
Recalling a register also selects that register number for all softkeys
which specify a register number in this menu. For example, if you want
to select register 5, press
Recall Reg. (Remember, you must first have
saved an instrument state to this register in the current sequence
identified by the
Select Seq softkey. If there is nothing saved, you cannot
recall it.) The recall register number becomes the active function. Enter
the number 5 using the numeric keypad and press the
Enter terminator
softkey. The instrument state is restored from this register and register
5 is now displayed in all softkeys which specify a register in this menu.
You can also use the front panel knob and the up and down arrow keys
to scroll through all saved registers for the selected sequence, recalling
each instrument state.
Softkey Location:
Recall > Recall Reg
