10 Installation Guide
E444xAU Options H20, H25 and H70 E444xAU IF Output Options
Installation Procedure
Figure 7 Rear Panel Plate with Option HNQ
Figure 8 Rear Panel Plate with Option H7L and HNQ
6960-0149
6960-0076
E4440-60413 E4440-60412
H7L IN
20 MHz or
25 MHz Label
H20 IN or
H25 IN Label
Hole Plug
6960-0149
E4440-60413 E4440-60412
20 MHz or
25 MHz Label
Hole Plug
