14 Installation Guide
E444xAU Options H20, H25 and H70 E444xAU IF Output Options
Installation Procedure
Figure 13 Top View Cable Orientation with Option H7L or HNQ
This concludes the installation of the E444xAU Option H7L or HNQ into the PSA
instrument.
Front
321.4 MHz Out
321.4 MHz IF In
321.4 MHz IF Out
Option IF Out
321.4 MHz IF Out
3rd Converter Board
Option IF Board
Option IF Out Cable
321.4 MHz IF Out
Cable
E4440-60412
W52
Option IF OUT
Option IF IN
E4440-60395
W41
(8120-5066)
