Chapter 11 389
Assembly Replacement Procedures
A26A1 DRAM and A26A2 Flash Boards
Replacement
NOTE Replacement DRAM and Flash boards are packaged with replacement
standoffs.
1. Install the new standoffs.
2. To replace the DRAM or Flash boards, align the connectors and pins
of the board over the holes and press down to seat the board.
3. Replace the A26 assembly. Refer to the “A26 CPU Assembly”
replacement procedure.
4. Replace the instrument top brace. Refer to the “Top Brace”
replacement procedure.
