6
Specifications (continued)
Sweep specifications Supplemental information
Sweep time
Range 2 ms to 1000 s Span ≥ 100 Hz
600 ns to 200 s Span = 0 Hz (zero span)
Sweep mode Continuous, single
Sweep time rule Accuracy, speed
Trigger source Free run, video, external, RF burst
Trigger slope Selectable positive or negative edge
Trigger delay ± 12 ms to ± 12 s Nominal, span = 0 Hz (zero span)
Front panel input/output Supplemental information
RF input
Connector and impedance Type-N female, 50 Ω Nominal
10 MHz reference/external trigger input
Reference input frequency 10 MHz
Reference input amplitude 0 to +10 dBm
Trigger voltage 5 V TTL level Nominal
Connector BNC female, 50 Ω Nominal
Probe power
Voltage/current +15 Vdc, ± 7% at 0 to 150 mA (nominal)
–12.6 Vdc, ± 10% at 0 to 150 mA (nominal)
GND
Connectivity
USB host USB Type-A female, compatible with USB
2.0 full speed
USB device USB Type-mini AB female, compatible with
USB 2.0 full speed
LAN RJ-45, 10 Base-T
General specifications Supplemental information
Display
Resolution 640 pixels x 480 pixels
Size and type 170 mm (6.5 in) TFT color display
Internal memory
System memory 64 MB For system use. Not user accessible
User memory 64 MB User accessible. Able to store about 14,000
traces
Languages
On-screen GUI English, Simplified Chinese, Traditional
Chinese, French, German, Italian,
Japanese, Korean, Russian, Spanish,
Portuguese
