7
Specifications (continued)
General specifications (continued) Supplemental information
Power requirements and calibration
Adaptor voltage 100 to 240 V AC, 50 to 60 Hz Auto-ranging
15 V DC, 5.3 A, 80 W max
Power consumption 16 W Typical
Battery operating time (fully charged
battery)
3.5 hours Tracking generator off, preamplifier on
3 hours Tracking generator on, preamplifier on
Charging time 3 hours
Life time 300 to 500 charge cycles
Warm-up time 5 minutes
Calibration cycle One year
Environmental and size
Temperature range –10 to +50 °C Operating (battery: 0 to 50 °C)
–40 to +70 °C Storage (battery: –20 to 50 °C)
Relative humidity < 95%
Weight 3.2 kg (7 Ibs) Net (shipping) approximately,
3.6 kg (7.9 Ibs) with battery
Dimensions 318 mm × 207 mm × 69 mm
(12.5 in × 8.15 in × 2.7 in)
Approximately (W × H × D)
Option specifications Supplemental information
Channel scanner (Option SCN)
Scan modes Top N, bottom N, and list
Channels displayed 1 to 20
Display orientation Vertical Number of channels ≤ 5
Horizontal Number of channels > 5
Chart Bar chart, and time chart
Log file .CSV and .KML
Spectrum monitor (Option SIM)
Display modes Spectrogram
Spectrum trace
Combination of spectrogram and spectrum
trace in one screen
RF preamplifier (Option P20)
Frequency range 1 MHz to 20 GHz
Gain 15 dB Nominal
Tracking generator (Option TG7)
Frequency range 5 MHz to 7 GHz
Output level 0 to –20 dBm 1 dB steps
VSWR < 2.0:1 Nominal
Connector and impedance Type-N female, 50 Ω
