9
Option specifications (continued) Supplemental information
Time-gated spectrum analysis (Option TMG)
Gated sweep (continued)
Gate sources External
RF burst
Periodic timer • Sync sources include free, external, and
RF burst
• Period: 0 to 20.0 s
(It should be greater than gate delay
plus gate length)
• Offset: –5 to +5 s
RF burst
Level range –60 to –20 dBm plus attenuation (nominal)
Bandwidth (–10 dB) 8 MHz (nominal)
Frequency limitations If the start or center frequency is too close
to zero, LO feedthrough can degrade or
prevent triggering. How close is too close
depends on the bandwidth.
Built-in GPS receiver and GPS antenna (Option GPS)
GPS information tagging Longitude, latitude, and altitude
GPS antenna Built-in
Frequency accuracy with GPS on ± 50 ppb
External GPS antenna connector SMA-F External GPS antenna, N934xC-GPA, is
offered as an optional accessory
USB peak and average power sensor support (Option PWP)
Power sensor supported Agilent U2020 X-series USB peak and
average power sensor
Frequency range 50 MHz to 40 GHz Sensor dependent
Peak power dynamic range –30 to +20 dBm
USB average power sensor support (Option PWM)
Power sensor supported Agilent U2000 Series USB power sensor
Frequency range 9 kHz to 24 GHz Sensor dependent
Dynamic range –60 to +44 dBm Sensor dependent
Security features (Option SEC)
Security erase Erase the entire user flash memory by
writing single character “1” over all
memory locations
Non-recoverable
Port control Disable/enable LAN port or USB port
Task planner for test automation (Option TPN)
Task plan execution mode Auto, manual, and manual if fail
Task plan file .TPN Complementary task plan editor is available
with HSA PC software
Number of tasks Maximum 20 in a single .TPN file
Measurements supported Regular spectrum analysis and power suite
(channel power, ACPR, and OBW)
Visit www.agilent.com/find/taskplanner for more information.
3. For efficiency and convenience, RBW is restricted to be equal to or greater than 1 kHz and VBW is restricted to be equal to RBW.
Specifications (continued)
