Specifications and Characteristics 3
U2000 Series Operating and Service Guide 55
Time-gated Measurements
Time-gate Parameters U2000 Series Performance
*
* Not applicable for U2004A
Sampling rate 1.47 Msps
Gate sweep time 0 s < Sweep time < 0.15 s
Gate offset time 0 s < Offset time < 0.15 s
Gate resolution ±1 µs
Gated power U2000/1/2A: –25 dBm to +20 dBm
U2000/1/2H: –15 dBm to +30 dBm
U2000/1B: +5 dBm to +44 dBm
Measurement speed 10 ms/reading
(Gate sweep time ≤ 2 ms,
Gate sweep time + Gate offset < 2.3 ms,
measurement rate FAST)
NOTE
The total value of gate sweep time and gate offset time has to be less
than 0.15 s, (Sweep time + Offset time < 0.15 s).
