AGL 304 - Cable Information

8
CABLE INFORMATION
POWER INPUT:
A GROUND BLACK
B 12 OR 24 V INPUT RED
MAST & VALVE (14 PIN CONNECTOR):
A AUXILARY POWER RED 16g
B NOT CONNECTED
C SOLENOID COMMON ORANGE 16g
D SENSOR ENCODER RED 20g
E SENSOR GROUND BLACK 20g
F SENSOR LOW GREEN 20g
G SENSOR HIGH WHITE 20g
H BLADE DOWN WHITE 16g
I ENCODER S1 BROWN 20g
J ENCODER S2 ORANGE 20g
K COMPENSATOR OUTPUT BLUE 16g
L MAST UP YELLOW 16g
M MAST DOWN BROWN 16g
N BLADE UP GREEN 16g
MAST TO DETECTOR CABLE 9-09826 (5 PIN CONNECTOR):
A NOT CONNECTED
B SENSOR GROUND BLUE
C SENSOR LOW BLACK
D SENSOR HIGH YELLOW/GREEN
E SENSOR POWER BROWN
HYDRAULIC VALVE CONNECTOR ON 1-14039 JUNCTION BOX
A COMPENSATOR OUTPUT
B GROUND (VALVE COMMON)
C BLADE DOWN
D BLADE UP
