MENU ITEMS:
The menu instructs you in how to change the factory default settings. You may customize the
system to suit any equipment, or to your personal preference.
To activate the MENU press the AUTO BLADE and SELECT buttons at the same time. The
display will show the flashing menu NUMBER on the left and the menu VALUE on the right. The
+ button will allow scrolling through the NUMBER list. The SELECT button allows cycling be-
tween the NUMBER and the VALUE. The + and - buttons will change the setting of the NUM-
BER function selected. When all changes are made, the AUTO BLADE button stores these
changes, resets all registers, and reactivates the system. On the next page is a list of the menu
numbers and the factory values.
* Center Channel Filtering affects sensor display lights, survey and hydraulic responses.
EXAMPLE
PROBLEM:
The scraper blade drops through center during a down correction.
SOLUTION:
Press AUTO BLADE and SELECT buttons at the same time. Press + or - on the left NUMBER
side. Press SELECT to make the right VALUE side numbers flash. Press - button twice to
reduce the Valve Speed setting from 04 to 02. Press AUTO BLADE to record the new settings
and exit the menu.
NO. DEFAULT VALUE DESCRIPTION
0 05 SENSITIVITY
REFERS TO CENTER CHANNEL FILTERING 0 TO
20; 20 IS MAXIMUM FILTERING SLOWEST
RESPONSE*
1 04 VALVE SPEED DOWN
REFERS TO VALVE SPEED DOWN NEAR
GRADE.0 TO 20; 20 IS THE FASTEST
2 06 VALVE SPEED UP
REFERS TO VALVE SPEED UP NEAR
GRADE. 0 TO 20; 20 IS THE FASTEST
3 05 MAST SPEED
REFERS TO MANUAL UP DOWN SPEED. 0 TO 20;
1 TO 10; 10 IS FASTEST USING MAST BRAKE. 11
TO 20; 20 IS FASTEST WITH NO BRAKING
4 02 ELEVATION UNITS
01 INCHES
02 FEET
03 METERS
5 00 VALVE TYPE
00 ON OFF VALVES
01 PROPORTIONAL VALVES
6 01 SURVEY TYPE
00 MANUAL DATA ENTRY
01 AUTOMATIC DATA ENTRY
02 CONTINUOUS DATA ENTRY
To Next Page
