COMPONENTS CHECKLIST
125-01: Mainmast (lower section)
125-02: Middle section of the
mainmast (E to I)
125-03: Upper section of the
mainmast (A to D)
125-04: Two vents and an
antenna (J to L)
125-05: Four heavy AA
gun mounts
125-06: Four twin barrels of the
AA guns
125-07: Four bases for the AA
guns
125-08: Metal parts (1 to 6)
The frame 125-03 in close-up shows three spars, A, C
and D and the upper mast section B. Carefully
remove all four parts from the frame.
Remove the four ladders 7 – 10 from the frame
125-09. Bend the tabs up at right angles. The lower
tab on part 8 is bent twice at right angles (forwards
and upwards) to form a U shape (arrow).
12501
12502
12503
12504
12507
12508
12509
12512
J
K
L
12505
12506
12510
12511
7
8
9
10
1
6
3
24
5
12503
A
B
D C
10
7
8
9
01. THE UPPER SECTION OF THE MAINMAST
125-09: Four ladders
(7 to 10)
125-10: Railing
125-11: Spar support
125-12: Antenna
STAGE 125
MAINMAST AND FOUR AA GUNS
