Place the upper mast section B on your worktop.
Check how the tabs on ladder 7 fit into the recesses
in part B (arrows). Apply a little superglue to fix in
place.
The short spar C fits across the mast: check the fit,
then apply a little superglue to fix the spar in place.
Turn the mainmast section B over and check the
fit of spar D. A peg on the mast fits into the socket
in the spar.
When you are happy with the fit apply a little
superglue to the peg and fix in place, ensuring
that both spars are parallel.
Take the tip of the mast, part 3 from the metal
frame 125-08. Very carefully, bend the central prong
upwards, at right angles to the two arms. Check the
fit on the upper end of mainmast section B.
When you are happy with the fit, glue the mast tip
3 in place, as shown.
07 08
0403
7
B
B
C
B
D
B
D
B
3
3
B
