Continuing with the eighth upper deck section
126-01, glue eight small skylights from frame
127-03 in place near the rear edge of the deck
section, as shown.
Take the aft upper deck section 127-01, supplied with
this stage. Glue the last skylight A and skylight B
from frame 127-02 in place in recesses, as shown.
Glue the two larger parts C and D from frame 127-02
into recesses on the upper deck section 127-01, next
to the parts fitted in step 4.
Glue the six remaining skylights from frame 127-03 in
place on the aft upper deck section 127-01, as shown.
Take the anchor chain opening F from frame
127-04 and glue it in place at the aft end of upper
deck section 127-01. Glue the anchor chain holder
E in line with it and the handwheel G on top of
part E, as shown.
Take the two parts M and N from the frame 127-06
and bend them along the three fold lines to make two
depth charge racks. They are mirror images of each
other, as shown above.
04
05
12701
12701
A
B
12701
C
D
03
12601
12703
12703
12703
12703
12701
E
F
G
N
M
