KEY TO PARTS
91A Left wall framework
91B Handle
91C Window bar
91D Window winder
91E Window frame
91F Sliding window pane
91G Window pane
91H Window pane
BP 1.5 x 3mm (x3)
OP 1.7 x 5mm (x5)
NM 1.5 x 3mm (x3)
EM 1.5 x 4mm (x5)
IMPORTANT!
Store your
model away from
direct sunlight, to
avoid damage to
the windows.
4
STAGE 91
FRAMEWORK AND WINDOWS FRAMEWORK AND WINDOWS
FOR THE LOWER DECKFOR THE LOWER DECK
A section of the lower deck framework is supplied and fitted with
windows and a handle.
NM
91A
91E
91D
91F
91B
91C
91G
91H
EM
OPBP
3
3
