3
4
1 2
1
Fit the window pane 91H to the inside of the left wall
framework 91A. Fix in place with four EM screws.
2
Cut away the mouldings that were used in
manufacture from the sliding window pane 91F and
the window frame 91E. Smooth any rough edges.
4
Fit the window frame 91E (with
sliding window pane 91F) on to the
outside of the left wall framework 91A. Fit
the window pane 91G to the inside of the
framework, as shown. Fix in place from
the inside of the window pane 91G with
four OP screws.
3
Fit the sliding window pane 91F
into the window frame 91E so that
ridges on the ends of part 91F fit into the
grooves in the frame 91E. The ‘metal’
edge goes at the top.
EM
x2
91H
91F
91A
91E
EM
x2
91A
OP
OP
91E
91F
4
4
AGORAMODELS ROUTEMASTER BUS
5
AGORAMODELS ROUTEMASTER BUS
