18
Parts list
NO. Parts Name Q'TY
101 CABLE GLAND (5/16") 1
102 SPRING WASHER (M6) 3
103-1 RECTIFIER & EMC (110V&220V) 1
105 CABLE CLIP 2
106 PANHEAD MACHINE SCREW (M4x30xP0.7) 3
107 CABLE PROTECTOR (5/16"x7CM) 1
108 CORD ARMOR 1
109 POWER SUPPLY CABLE 1
110 SIDE PANEL (126.8x86.7x1.5T) 1
111 PANHEAD MACHINE SCREW (M4x8xP0.7) 8
112 CRANK SPINDLE (Ø28) 1
113 CRANK HANDLE 3
114 ELECTROMAGNET (179x80x48) 1
115 WIRE LEAD (1015-16#18CM) 2
116 GIB STRIP-LEFT (258MM) 1
117 GIB STRIP-RIGHT (258MM) 1
118 GIB TENSIONER (258x11x1.2T) 1
119 TRAVEL LIMITER STOP 1
120 HEX NUT (M8) 1
121 SOCKET SET SCREW (M8x100xP1.25) 1
127 HEX KEY (M2.5) 1
128 HEX KEY (M4) 1
130 PANHEAD MACHIME SCREW (M4x16xP0.7) 1
131 DEPTH LOCK LEVER 2
136 CHECK BALL (Ø8) 2
145 FEMALE SPADE TERMINAL 4
146 RUBBER WASHER (Ø4xØ11x1) 2
NO. Parts Name Q'TY
147 SPADE TERMINAL BOOT 8
150 CHUCK (1/2") 1
154 THUMB SCREW (M5x8) 2
155 EARTHING MARKING 1
156 BUTTERFLY SCREW (M6x10xP1.0) 2
157 FLAT WASHER (Ø6xØ13x1) 2
159 SPINDLE (Ø31) 1
160 INTERNAL CIRCLIP (IS42) 1
161 SPRING (Ø2.5xØ43xØ48x3Tx25L) 1
162 QUICK-RELEASE COLLAR (Ø58) 1
163 THRUST WASHER (Ø42.6xØ51.8x2) 1
164 RETAINING RING (Ø2.5xØ39.6xØ44.6) 1
165 ANNULAR CUTTER ARBOR (Ø31) 1
166 QUICK-RELEASE CHUCK ADAPTORS (Ø31) 1
167 UNIVERSAL TAP CHUCK (Ø31) 1
168 PUSH LOCK FITTING (PT1/8"xØ6) 1
169 SELECTOR TAB 1
170 DETENT PIN (Ø5x22) 1
171 SPRING (Ø0.6xØ5.3xØ6.5x17Lx5T) 1
172 E-CLIP (E-3) 1
173 SAFETY BELT 1
174 ZIP TIE (2.5x100MM) 1
175 CHIP GUARD 1
176 BRUSH SPRING (0.35x3x3T) 2
177 PANHEAD MACHINE SCREW (M4x10xP0.7) 2
178 PANHEAD TAPPING SCREW (M4x12) 4
181 WRENCH (M8) 1
