AGP TP2000 - Parts List

17
Parts list
NO. Parts Name Q'TY
4 SOCKET SET SCREW (M8x7xP1.25) 2
6 WATER SEAL (Ø16x16) 1
7 SPRING (Ø1.5xØ13.3xØ16.6x16Tx100L) 1
10 BALL BEARING (6205) 1
11 OIL SEAL (Ø22xØ32x7) 2
12 PANHEAD MACHINE SCREW (M5x170xP0.8) 4
13 INTERNAL CIRCLIP (R-52) 1
14 GEAR HOUSING 1
16 BUSHING 1
17 NEEDLE BEARING (TA 2210) 1
18 TAP REVERSING GEAR (M1.5x33T) 1
19 TAP SPINDLE ENGAGEMENT GEAR 1
20 EXTERNAL CIRCLIP (S-17) 1
21 NEEDLE BEARING (HK 1010) 4
22 PARALLEL KEY (4x4x30) 1
23 REVERSING DRIVE GEAR (M1.25x24T) 1
24 PARALLEL KEY (5x5x12) 2
25 REVERSING DRIVE GEAR (M1.5x12T) 1
26 LOWER GEAR CASE 1
27 SPRING (Ø1xØ9xØ11x11Lx4T) 1
28 FAN BAFFLE 1
29 SHOULDER SCREW 1
30 FLAT HEAD MACHINE SCREW (M4x8xP0.7) 2
31 SELECTOR BASE 1
32 SHIFT PIN (Ø6x19.5) 1
33 SELECTOR COLLAR PIN (Ø12x41) 1
34 RETAINING RING (Ø1.5xØ23xØ26) 1
35 TAP FORWARD GEAR (M1.25x42T) 1
36 NEEDLE BEARING (TA 2515) 1
37 THRUST WASHER (Ø25xØ40x1.5) 1
38 DRILLING SPINDLE GEAR (M1.25x27T) 1
39 THRUST RING (0816) 1
40 EXTERNAL CIRCLIP (S-8) 1
41 NEEDLE BEARING (HK 0810) 1
42 PANHEAD MACHINE SCREW (M5x10xP0.8) 3
43 GEAR PLATE 1
44 BALL BEARING (608) 3
45 INPUT SHAFT (M1.0x8T) 1
46 PARALLEL KEY (4x4x10) 1
47 INPUT GEAR (M0.7x50T) 1
48 INTERMEDIATE PINION (M1.25x11T) 1
49 PARALLEL KEY (5x5x15) 1
NO. Parts Name Q'TY
50 DRILLING INTERMEDIATE GEAR (M1.25x26T) 1
51 EXTERNAL CIRCLIP (S-16) 1
52 LAY GEAR (M1.0x52T) 1
53 EXTERNAL CIRCLIP (S-14) 1
54 GEAR PLATE 1
55 BALL BEARING (609) 1
56 ARMATURE (220V-73x42x45) 1
57 PANHEAD TAPPING SCREW (M5x60) 2
58 STATOR (220V-73x42x45) 1
59 MOTOR HOUSING 1
60 CARBON BRUSH HOLDER (7x11) 2
61 CARBON BRUSH (7x11x17) 2
63 MOTOR TAIL CASTING 1
64 PANHEAD TAPPING SCREW (M4x30) 2
65 CABLE PROTECTOR (5/16"x45CM) 1
66 WIRE (1.25x2Cx65CM-VCTF) 1
67 EXTERNAL STAR WASHER (M5) 1
68 HEX NUT (M4xP0.7) 6
69 CABLE CLAMP 2
70 CRIMP CAP CONNECTOR (C4) 3
72 PANHEAD TAPPING SCREW (M4x14) 2
73 COOLANT TANK ASSEMBLY 1
78 TUBE (Ø4xØ6x20CM) 1
79 COOLANT TANK BRACKET 1
80 FLAT WASHER (Ø5xØ12x1) 4
81 THUMB SCREW (M5x16) 3
82 SLIDE PLATE (L310.5MM) 1
83 SOCKET CAP SCREW (M6x20xP1.0) 6
84 SOCKET CAP SCREW (M5x16xP0.8) 2
85 GEAR RACK (M1.5) 1
86 SOCKET CAP SCREW (M8x16xP1.25) 2
88 SWITCH PANEL (126.8x86.7x1.5T) 1
89 FLAT WASHER (Ø4xØ10x1) 2
92 SOCKET CAP SCREW (M6x16xP1.0) 1
93 FLAT WASHER (Ø6xØ25x1) 1
94 FLAT WASHER (Ø6xØ40x2.5) 1
95 BUSHING (Ø28xØ32x12) 2
96 MOTOR SWITCH (220V) 1
97 MAGNET SWITCH (110V&220V) 1
98 HEX NUT (M5xP0.8) 5
99 SOCKET SET SCREW (M5x20xP0.8) 5
100 STAND BODY 1
