agratronix WINDROW - Operation; COMPONENTS; OPERATIONAL MESSAGES

10-1
Operation
COMPONENTS
KEY PART NO. DESCRIPTION
1 *07253 SENSOR
2 *PLA-D0103 BATTERY DOOR
3 *07141 TESTER BODY
*Indicates manufacturers part numbers
OPERATIONAL MESSAGES
Symbol Definition
BATLO ............... System battery needs replacing
HI ................................... Moisture is above limit
LO ..................................Moisture is below limit
1
2
3
