AGRI EASE BE-AGL125F - Exploded View 1-5 & Parts

BE-AGLxxxF USER MANUAL 15
1-2
REF SYSTEM NO. PART NO. DESCRIPTION QTY
1
501011131 GB5783-M12X55
Screw bolt
2
2 506030037
GB93-12
Spring washer
10
3 506010057
GB97.1-12
Flat gasket
10
4 503010047
GB6170-M12
Hex nut
2
5 810240082
EFAGL165A-1400-00
Gear box pull rod
2
6 810240065
EFAGL165A-0500-00
Gear box seat
1
7 801240040
XH50.300Z.02W
(EFGC884) Gear box
1
8 802710038
EFAGL125.014
Tensioning plate
1
9 501011126
GB5783-M12X30
Screw bolt
6
10 501011129
GB5783-M12X45
Screw bolt
2
11 503010100
GB6172.1-M12
Thin nut
2
12 702420030
EF100.00.177
Rust proof cover
1
13 501011111
GB5783-M10X20
Screw bolt
2
14 506030036
GB93-10
Spring washer
2
15 506010036
GB96.1-10
Large flat gasket
2
16 703400008
FM120.00.199
PTO cover
1
17 710240027
EFAGL165A-0000-06
ROP set pin 1
1
18 506010037
GB96.1-12
Large flat gasket
2
19 701680001
EFGCHM120.101
Plywood
1
20 501011128
GB5783-M12X40
Screw bolt
2
21 503010763
DIN985-M12
Thin nut
2
22 700080010
200.56.011
Lock pin
1
1-2
