AGRICOW BRUSH - Using the Machine; Dichiarazione DI Conformità Ce

PENDULUM BRUSH
PENDULUM BRUSH
Use and Maintenance Instructions
3
EN
Use and Maintenance Instructions
3
EN
Technical data:
N. motori
1
Tensione di alimentazione
220V – 110V
Frequenza
50 – 60 Hz
Potenza
0,75 Cv
Consumo
0,55 Kw/h
Peso dell’assieme
Kg 80
Dimensione spazzola
50x100
Durata di rotazione pre(pre(preimpostata) Ca 90
sec
Velocità di rotazione
50 giri/min
Picchi di corrente massimi 0 A – 12 A efficace
Temperatura di esercizio -15°C + 55 °C
Protezione motore Fusibile 10 A
USING THE MACHINE
Inspection and controls before use:
ThemachineischeckedonAgricowpremisesbeforedeliveryasforeseenbyinternalprocedures.
Use:
The cattle brush has been designed and produced for use as a system for cleaning the coat of dairy cows. One
brush should be used for every 50/60 cows.
IT MUST NOT BE USED for any purpose other than cleaning the coat of cattle.
Activation:
•Whentheanimalpushesagainstthebrush,amicroswitchstartstoturntheroller,which
automatically proceeds to clean the animal without requiring assistance by staff.
 •Bymeansofthestartmotorcontact,theboardcontrolsthestartandendofaworkcycle.
When the device is started, the electronic board begins a brush rotation procedure which
lasts 90 seconds. When the device is started again, the motor turns in the opposite direction
to the previous cycle so the brush is used evenly.
DICHIARAZIONE DI CONFORMITÀ CE
DICHIARAZIONE DI CONFORMITÀ CE
Overall dimension
No. motors
Voltage supply
Frequency
Capacity
Consumption
Overall weight
Brush dimension
Rotation time (preset)
Rotation speed
Maximum power surges
Operating temperature
Motor protection
110x175h cm
1
220V – 110V
50 – 60 Hz
0.75 Cv
0.55Kw/h
80kg
50x100
Approx. 90 sec
36 rev/min
0 A – 12 A effective
-15°C + 55 °C
10 A fuse
Pendulum
