• Specifications
18
Outputs 1V / 500 (Rated), 2.4V (Max.)
Input 50mV / 1M Stereo (Rated),
50mV / 500k Mono (Rated),
100mV for Max. Output
Distortion 0.02% THD
S / N Ratio 80dB
Frequency Response 20Hz - 20kHz (±2dB)
Digital Processor 18 Bit Digital Effects Processor
Maximum Delay 1200 Milliseconds
Main Programs 16
Total Preset Combinations 256
Indicators Power LED,
Signal LED (7dB prior to true clip)
Power Supply AC: 9V (Adaptor provided)
Dimensions W200 ? H45 ? 150 mm
Net Weight 0.90kg
• Design and Specifications are subject to change without notice owing to continuous product upgradation.
• Technical specifications are subject to production tolerances.
