Dimensions
Overall Length Overall Width Overall Height SWL
250kg
Single: 2288mm 900mm 110-740mm 250kg
King Single: 2288mm 1060mm 110-740mm 250kg
Mattress Size
MODEL Single King Single
Recommended Mattress Size
Maximum Mattress Depth
Width = 900 mm Width = 1050 mm
Length = 2000 mm Length = 2000 mm
Depth = 170 mm Depth = 170 mm
Bed Weight & Safe Working Load
Bed Weight – Single 105kg
Bed Weight – King Single 115kg
SWL (Safety Factor 2 x SWL)
250kg
= 250kg
Max User Weight
200kg (makes allowance for accessories like mattresses
air mattresses and pumps, bed poles etc)
= 200kg
Electrical Parameters
Power Input 230V AC 50Hz, Max current 1A
Rate Load Interruption 10%, Max 2 minutes / 18 minutes
Leakage Protection
Class 1 Type B
Waterproof Grade IP54
Standards Compliance
Aidacare FL250 Beds are designed and manufactured where required in
compliance with International Medical Device Safety standard IEC60601-1,
IEC60601-2-52. All electronics are designed for use in Acute Care environments
and comply with all relevant Electrical Safety Standards.
3. OVERVIEW
The Aidacare FL250 Bed has been designed specifically for the aged care and
hospital environment. Please take the time to familiarise yourself with the key
components shown below:
Mattress
retainers
Adjustable
mattress
retainer
Central locking
castors
Wall buffer
Directional locking
castors
Available in single
or king single widths
(King single shown)
Under-bed
lighting
Attendant control
panel (incl. head and
foot board accessory)
Handset
holder
bracket
Backlit
handset
Day
Mode
Night
Mode
4. SPECIFICATIONS
0º – 60º
0º – 35º
NOTE: Backrest and knee bend
angle is the same across both
Single and King Single beds
