2.3 Install the sight
To install the sight to an interface compatible with the
integrated mount shown in Fig. 1, follow the described
procedure:
a Loosen the screw (5) using the Torx T10 of the Aimpoint
tool (8D) and clamp the locking bar (4) around the
dovetail interface.
b With the recoil stop positioned in a recess, push
the sight forward (toward muzzle) and tighten the
screw (5).
c Tighten the screw (5) until a light resistance is
encountered. Proceed with another 1/4 to 1/2 turn until
fully tightened (MAX. 3 Nm / 2.2 ft·lb).
d Retighten the screw (5) after initial ring to ensure the
sight is securely fastened.
CAUTION: Do not overtighten.
2.4 Zeroing
CAUTION: Do not continue to adjust windage and
elevation screws (6) (7) if you encounter resistance.
a Adjust the intensity to a comfortable setting for the red
dot to contrast clearly against the target.
b Use the Torx T10 of the Aimpoint tool (8D) to turn the
adjustment screws (6) (7).
