L4 BASS PREAMP 10
PARTS LIST, CONT.
PART VALUE TYPE NOTES
FREQUENCY 100kC dual 16mm dual pot, right angle
TREBLE 2 25kB 16mm right-angle PCB mount pot
VOLUME 2 10kB 16mm right-angle PCB mount pot Original uses 2.5kA. See build notes.
MASTER 25kA 16mm right-angle PCB mount pot
LIMIT 50kC 16mm right-angle PCB mount pot
DEEP 1 DPDT Toggle switch, DPDT on-on
DEEP 2 DPDT Toggle switch, DPDT on-on
COMP SPDT Toggle switch, SPDT on-on
BYP. LED 5mm red LED, 5mm, red diffused
CH. 1 LED 5mm green LED, 5mm, green diffused
CH. 2 LED 5mm red LED, 5mm, red diffused
LIMIT LED 3mm red LED, 3mm, red diffused
DC JACK 2.1mm DC jack, 2.1mm panel mount Mouser 163-4302-E or equivalent.
IN 1/4" mono 1/4" phone jack, closed frame Switchcraft 111X or equivalent.
OUT 1/4" mono 1/4" phone jack, closed frame Switchcraft 111X or equivalent.
BYPASS 3PDT Stomp switch, 3PDT
CHANNEL 3PDT Stomp switch, 3PDT
ENCLOSURE 1590XX Enclosure, die-cast aluminum
