L4 BASS PREAMP 5
PARTS LIST
This parts list is also available in a spreadsheet format which can be imported directly into Mouser for
easy parts ordering. Mouser doesn’t carry all the parts (most notably potentiometers) so the second tab
lists all the non-Mouser parts as well as sources for each.
View parts list spreadsheet →
PART VALUE TYPE NOTES
R1 10k Metal film resistor, 1/4W
R2 220k Metal film resistor, 1/4W
R3 47k Metal film resistor, 1/4W
R4 2k2 Metal film resistor, 1/4W
R5 1k Metal film resistor, 1/4W
R6 22k Metal film resistor, 1/4W
R7 5k1 Metal film resistor, 1/4W Taper resistor for Mid pot. See build notes.
R8 22k Metal film resistor, 1/4W
R9 22k Metal film resistor, 1/4W
R10 470k Metal film resistor, 1/4W
R11 47k Metal film resistor, 1/4W 18k in the original amp, but 47k provides better channel matching.
R12 10k Metal film resistor, 1/4W
R13 2k7 Metal film resistor, 1/4W Taper resistor for Volume 1 pot. See build notes.
R14 1k Metal film resistor, 1/4W Taper resistor for Volume 1 pot. See build notes.
R15 6k8 Metal film resistor, 1/4W
R16 2k2 Metal film resistor, 1/4W
R17 1M Metal film resistor, 1/4W
R18 4k7 Metal film resistor, 1/4W
R19 4k7 Metal film resistor, 1/4W
R20 2k2 Metal film resistor, 1/4W
R21 220k Metal film resistor, 1/4W
R22 120k Metal film resistor, 1/4W
R23 220k Metal film resistor, 1/4W
R24 3k3 Metal film resistor, 1/4W
R25 120k Metal film resistor, 1/4W
R26 18k Metal film resistor, 1/4W
R27 1k Metal film resistor, 1/4W
R28 4k7 Metal film resistor, 1/4W
R29 10k Metal film resistor, 1/4W
R30 5k6 Metal film resistor, 1/4W
R31 22k Metal film resistor, 1/4W
R32 22k Metal film resistor, 1/4W
Interactive BOM →
