Air Conception TORNADO 280 - Tightening torque

19/04/2019 V2.0 Page 21 of 24
8. Tightening torque
M8 Cylinder head nuts
23 Nm
M5 Crankcase screws
10 Nm
Spark-plug
26 Nm
M6 and M8 reduction screws
15 Nm
M5 reed valve body screws
4 Nm
M5 crankcase screws 10 Nm
M10 Crankshaft pulley nut 40 Nm
M5 Ignition coil screws 10 Nm
M5 Starter sprocket screws 10 Nm
M6 electric starter screws 13 Nm
M5 x 16 mm electric starter bracket screws
M5 x 20 mm electric starter bracket screw
5 Nm
2 Nm
M5 Carburetor plastic connector screws 3 Nm
M6 Electravia carbon propeller screws 10 Nm
1 kg/m = 9.81 Nm
