II) Technical Specifications - Performance
a) Technical Specifications
Area 13.5 sqm
Airfoil type 40% double surface
Span 10 m
Nose angle 122°
Aspect ratio 7.4
Empty weight 38 kg
Tested structured strength + 1,350 kg
- 650 kg
Ultimate load factors +6g -3g
with max weight 250 kg
Limit load factors + 4g -0g (-2g under gust)
b) Maximum added load
The maximum load which may be added under the wing is 212 kg. The following chart defines the useful load of
our different trike models.
RACER 447 RACER 503 RACER 503 SL RACER 503 S
Maximum useful
load
140 kg 135 kg 129 kg 125 kg
Any trike, built by an amateur or in series production, of a total maximum weight under 212 kg may be fixed under
the wing. The necessary engine power for a safe flight should be at least 25 CV. Check when fitting whether the
trike propeller stays clear of the lower rear longitudinal cables and the keel. A maximum clearance of 10 cm of
should be respected since the wing is its most backward position.
c) Performance with maximum weight
TRIKE
RACER 447 RACER 503 RACER 503 S-
SL
Stall speed 38 km/h 38 km/h 38 km/h
Minimum level flight speed 40 km/h 40 km/h 40 km/h
Take-off run 40 m 35 m 40 m
15 m clearing distance 100 m 85 m 90 m
Climb rate 5,5 m/s 7 m/s 7 m/s
Landing distance from 15 m height 140 m 140 m 140 m
Max L/D ratio 6 6 6
Max glide ratio speed 45 km/h 45 km/h 45 km/h
Side wind limits 30 km/h 30 km/h 30 km/h
V.N.E. (speed never to be exceeded) 110 km/h 110 km/h 110 km/h
V.man (never to be exceeded in very
turbulent air)
80 km/h 80 km/h 80 km/h
