Ceiling Cassette
The SLIMLINE PERFORMER Ceilin
g
Cassette
–
Ductless Mini-S
p
lit
15
Technical Manual : AIR 8-105.
5
Table 15.1 – Technical Data – DX Cooling Only and Heat Pump Units
Units CSD/CSH 18 CSD/CSH 24 CSD/CSH 30 CSD/CSH 36 CSD/CSH 42
Nominal Cooling Capacity (1) BTU/h 19200 23000 31400 38200 42500
Nominal Heating Capacity (2) BTU/h 16400 21400 27400 32400 37200
Nominal System SEER (3) 13 13 13 13 13
HSPF 7.7 7.7 7.7 7.7 7.7
Construction
Material: Fascia High Impact Polystyrene
Material: Chassis Galvanized Steel
Color: Fascia Pearl Grey
Fire rating UL94 VO
Evaporato
r
Type
Finned Tube
Quantity 1 1 1 1 1
Face Area Ft² 4.0 4.0 5.2 5.2 5.2
Nominal Airflow High cfm 590 670 920 1000 1130
Med cfm 540 590 800 920 1000
Low cfm 465 540 680 800 920
Discharge 4-way 4-way 4-way 4-way 4-way
Fan
Type
Centrifugal
Quantity 1 1 2 2 2
Diameter in 14 14 14 14 14
Horsepower (per fan) HP 1/8 1/8 1/8 1/8 1/8
Refrigeration
Number of Circuits 1 1 1 1 1
Refrigerant Type R-410A R-410A R-410A R-410A R-410A
Weights
Weight - Chassis lb 66 66 97 97 97
Weight - Fascia lb 18 18 21 21 21
Connections (4)
Suction in 3/4 3/4 3/4 3/4 3/4
Liquid in 3/8 3/8 3/8 3/8 3/8
Condensate (ID) in 3/8 3/8 3/8 3/8 3/8
Filtration
Type
Wire Framed Periframe
Quantity 2 2 3 3 3
Arrestance 80% 80% 80% 80% 80%
Condensate Pump
Maximum Head in 30 30 30 30 30
Nominal Flowrate gpm 0.1 0.1 0.1 0.1 0.1
Options
Electric Heating Capacity kW 3.0 3.0 5.0 5.0 5.0
HW Heating Capacity (5) BTU/h 38,746 41,993 56,609 59,600 64,268
HW Coil Connection (OD) in 7/8 7/8 7/8 7/8 7/8
Max Branch Duct Connections (qty) 2 2 2 2 2
Branch Duct Diameter in 5 5 6 6 6
Branch Duct Air Volume (6) cfm 115 130 180 200 220
Fresh Air Connections (qty) 1-3 1-3 1-3 1-3 1-3
Fresh Air Duct Diameter in 3 3 3 3 3
Fresh Air Volume (7) cfm 60 65 85 90 95
(1) Nominal cooling capacity based on 80/67°F DB/WB and 95/75ºF DB/WB ambient
(2) Nominal heating capacity based on 70/60°F DB/WB and 47/43°F DB/WB ambient.
(3) Test conditions based on ARI 210/240.
(4) Refrigerant line sizes should always match condensing unit connection sizes.
(5) Nominal heating capacity based on 70/60°F DB/WB and water temperature of 180ºF inlet / 160ºF outlet.
(6) Maximum air volume available through one branch duct 6' long, with Cassette fan(s) at high speed and corresponding fascia
aperture closed.
(7) Maximum fresh air through all knockouts connected to one 10' long duct with fan at high speed.
