Airflow DUPLEXVENT DV72 R - Page 11

1
1
Installation Instructions
SECOND FIX
–
installing Vertically Hung Unit
Airflow and drain fitting - LH
Airflow
and
drain
fitting
-
RH
Drains are factory fitted.
The units has either a LH or RH drain.
T
o atmosphere
From atmosphere
Extract from dwelling
Supply to dwelling
Supply to dwelling
Extract from dwelling
From atmosphere
T
o atmosphere
W
all
mount
W
all
mount
