1.5.2.2.5. AC load current (I)
When receiving Meter Get Command, it will report Meter Report Command to the node.
Meter Get Command:
[Command Class Meter, Meter Get, Scale =0x05(I)]
Meter Report Command:
[Command Class Meter ， Meter Report ， Rate Type = 0x01 ， Meter Type =0x01，
Precision = 2
，
Scale = 0x05
，
Size = 2
，
Meter Value(I)]
Example:
Scale = 0x05 (I)
Precision = 2
Size = 2 (2 Bytes of I)
Meter Value 1 = 0x01(I)
Meter Value 2 = 0x21(I)
AC load current = (Meter Value 1*256) + (Meter Value 2) = 2.89 (A)
1.5.2.2.6. load power factor (PF)
When receiving Meter Get Command, it will report Meter Report Command to the node.
Meter Get Command: [Command Class Meter, Meter Get, Scale =0x06(PF)]
Meter Report Command:
[Command Class Meter，Meter Report，Rate Type = 0x01，Meter Type =0x01，
Precision = 2
，
Scale = 0x06
，
Size = 1 Bytes
，
Meter Value(PF)]
Example:
Scale = 0x06 (PF)
Precision = 2
Size = 1 (1 Byte of PF)
Meter Value 1 = 0x63(PF) (It means that the load power factor is 0.99)
1.5.3. Z-Wave’s Configuration
Configuratio
n Parameter
Function
Size
(Byte)
Value
Unit
Default
Description
1
Watt Meter
Report Period
2
0x01-
0x7FFF
5s
720
720*5s=3600s=1
hour
2
KWH Meter
Report Period
2
0x01-
0x7FFF
10min
6
6*10min=1 hour
3
Threshold of
current for
Load caution
2
10-1100
0.01A
1100
1100*0.01A =
11A
4
Threshold of
KWh for Load
2
1-10000
1KWh
10000
