1.5.2.1. Auto report to Grouping 1 (Maximum Node 1)
1.5.2.1.1. On/Off Event Report
When “on” or “off” state has been changed, it will send Binary Switch Report to the node of
Grouping 1.
Binary Switch Report
ON:[Command Class Switch Binary, Switch Binary Report, Value =255(0xFF)]
OFF:[Command Class Switch Binary, Switch Binary Report, Value =0(0x00)]
1.5.2.1.2. Instant Power Consumption vary over 5% report
When the power consumption of load vary over 5%, it will send Meter report to the nodes of
Grouping 1.
Meter Report Command:
[Command Class Meter
，
Meter Report
，
Rate Type = 0x01
，
Meter Type =0x01
，
Precision = 1，Scale = 0x02，Size = 4，Meter Value(W) ]
1.5.2.1.3. Overload alarm report
When Plug detects the current is more than 14.5A, it will send Alarm Report to Group 1
node.
The content of Alarm Report
Alarm report command:
[Command_Class_Alarm, Alarm_Report, Alarm Type = 0x08, Alarm Level =0xFF]
1.5.2.2. Response to Meter Get Command
The Switch will report its (1) instant Power Consumption (Watt) or (2) accumulated power
consumption(KWH) or (3) AC load Voltage (V) or (4) AC load current ( I ) (5) load power
factor (PF) to Z-Wave Controller after receive the Meter Get Command from Z-Wave
Controller.
1.5.2.2.1. Instant Power Consumption (Watt) of Switch
When receiving Meter Get Command, it will report Meter Report Command to the node.
Meter Get Command: [Command Class Meter, Meter Get, Scale =0x02(W) ]
Meter Report Command:
[Command Class Meter，Meter Report，Rate Type = 0x01，Meter Type =0x01，
Precision = 1
，
Scale = 0x02
，
Size = 4
，
Meter Value(W) ]
Example:
Meter Value 1 = 0x00 (W)
Meter Value 2 = 0x00 (W)
Meter Value 3 = 0x03 (W)
