2.2.2 Moving parts

NOTICE

Loose objects, hair, and jewelry may get snagged on rotating parts and dragged into the unit

Do not wear jewelry or loose objects while working with rotating parts. Protect long hair by wearing

headgear.

NOTICE

Body parts that come in contact with rotating parts can suffer minor or moderate damage.

Avoid making unfavorable contact with the unit and make sure that all parts are stationary before

working on the unit.

Dropping the air handling unit can result in damage or injuries to humans or objects. If the unit is

removed from the wall, for example during cleaning, it should be placed carefully on the internal cover

on a level surface.
