3.6 EU Declaration of Conformity

EU Declaration of Conformity can be found in Appendix A on page 30. The most recent version is always available on

our website.

Direct link: EU Documentation

, choose ’EU Declaration of Conformity’.

3.7 Certificates

AM 50 is Eco Label certified, please see Appendix B on page 31. The most recent version is always available on our

website.

Direct link: EU Documentation

, choose ’Eco Labels’.

3.8 Warranty

The unit comes with a 24-month warranty, for further information see Terms of Sale and Delivery.

The warranty is voided if:

• Error messages are ignored.

• If the filters are not changed when the filter change identification flashes, or when this is not done according

to the manual.

• Instructions provided in this manual are not adhered to.
