AB1561 Headset Reference Design
User Guide
© 2020 Airoha Technology Corp.
Page 4 of 14
This document contains information that is proprietary to Airoha Technology Corp. (“Airoha”) and/or its licensor(s).
Any unauthorized use, reproduction or disclosure of this document in whole or in part is strictly prohibited.
Functionality Actions Results Requirements
Reset to factory
Tap key1 (Regen) -> wait 1 sec ->
press key1 (Regen) + key3(PIO5)
One median beep
In the power off
state.
2.1.3. Language selection
The user could change the language of the system.
Table 3. Language selection
Functionality Actions Results Requirements
Change the
language of the
system
Double-tap key3 (PIO5)
Double long beep and a voice
prompt says “English voice
prompt”
System is active
2.1.4. ANC
Ambient unwanted sound is significantly reduced when ANC is on. ANC uses aural overlap and destructive
interference to attenuate surrounding noises.
Table 4. ANC
Functionality Actions Results Requirements
ANC on
Triple-tap key5 (PIO4)
Two falling beeps
In power on, during
pairing mode,
connected, call active
states
ANC off
Triple-tap key5 (PIO4)
Two falling beeps
In power on, during
pairing mode,
connected, call active
states
2.1.5. AiroThru
When the AiroThru functionality is on, the user can hear the surrounding sound without removing their
headphones. Essentially, users can still hear traffic, broadcasts, or chatting when they are listening to music or
audio.
Table 5. AiroThru
Functionality Actions Results Requirements
AiroThru on
Press key7 (PIO3) for three seconds
Rising beeps
In power on, paring
mode, connected
states
AiroThru off
Press key7 (PIO3) for three seconds
Rising beeps
In power on, paring
mode, connected
states
2.1.6. Google Fast Pair
