SPECIFICATIONS*
1.0 1.7
Dimensions: 27¼" × 17¼" × 7” ** 27" × 22" × 14" (L × W × H)
Weight: 26 lbs 38 lbs
Speed Settings: 2 2
Tested Airow: 600 / 1047 CFM 1000 / 1712 CFM (Low / High)
Tested Power: 55 / 88 watts 105 / 159 watts (Low / High)
Tested Noise***: 43 / 53 dBA 44 / 55 dBA (Low / High)
Insulation R-49 R-47 (Standard / XR)
Rough Opening: 14½" × 22½"
Grille Dimensions: 16½" × 24½" (cube-core, powdercoated white
Electrical: 120 VAC, 60 Hz, 2.0 / 1.0 amps (1.7 / 1.0)
Installation: Installs easily on 16" or 24" O/C joists
Controls: Low Voltage; hardwired Digital Touch Controller, optional wireless remote
Warranty: 3 years parts; 1 years controls
* Actual performance will vary from installation to installation. Due to our continual product improvement efforts,
performance ratings and specications are subject to change without notice.
** Requires at least 20" of overhead clearance for the damper door to open fully.
*** Tested at 45º and 1 meter from source.
AirScape 1.0 & 1.7 Whole House Fan Installation Manual, 03222018
©AirScape, Inc., 2018. All Rights Reserved.
Page 7
MAINTENANCE, TROUBLESHOOTING, TECHNICAL SUPPORT
There is no routine maintenance required for this fan other than making sure the fan and its damper door(s) remain
clear of dust or debris, and that the area in front of the fan remains as unobstructed as possible, with no object
closer than 24" to the face of the fan.
A resettable circuit breaker is located on the fan-mounted electrical box to protect circuit boards from power surges.
In the case of a power surge, this breaker can be reset by simply pushing the button back in.
If problems are encountered, please take a few moments to run through the troubleshooting procedures
described on the blue Warranty Card. If these suggestions do not work, contact AirScape technical sup-
port at 1.866.448.4187 or by email at experts@airscapefans.com for further assistance.
