PLUMBING
G - 13
G
2. Turn the water heater bypass
valve to its bypass position. The
valve is located on the back of
the water and accessed through
the rear doors under the curbside
rear lounge seat on the rear
lounge model and through and
access hole cut in the roadside
twin bed top on the twin bed
model.
3. Attach a length of hose to the
waterpump inlet port. This
piece of hose should be long enough for the free end to be inserted into
and reach the bottom of a non-toxic RV antifreeze container.
5. Check that all interior water faucets are still open.
6. Insert hose length into container containing non-toxic RV antifreeze, turn the
pump on, and run the water pump until the antifreeze solution fills all water
lines. Flush toilet.
7. Open exterior shower faucet until anti-freeze comes out hose, shut off valve,
remove and drain valve/hose assembly.
8. Close water fixtures as the antifreeze begin to come out. Shut off pump when
antifreeze has been distributed through out system, then reopen all faucets
to relieve pump pressure.
9. Disconnect the hose length from pump inlet fitting and reconnect water
system inlet line.
Restoring Service
Re-install fully charged house battery.1.
Close low point drain valves, holding tank dump valves, water faucets, 2.
and fresh water tank drain.
Reconnect water pump line.3.
Add water to the fresh water tank. 4.
Turn water pump on. 5.
Open and close faucet valves one at a time until water runs clear at all 6.
faucets signaling anti-freeze is flushed out of lines. Go back and recheck
water clarity at all faucets.
Turn off water pump.7.
Hook up city water, open faucet valves, and recheck water clarity.8.
Replace water heater plug or close drain valve and reset water heater 9.
by-pass to the “in use” position.
Fill water heater.10.
By Pass Position
In Use Position
By Pass Valve
