into the wall mounted shower inlet. The assembly can only be inserted and
removed with handle aligned to the off position. Press the spout button and
rotate the handle counter clockwise to the desired temperature. To remove
handle assembly, return the handle to the off position, press the spout button
to relieve any residual pressure and pull the handle out of the wall insert. Snap
cover completely shut so rubber o-ring seal will seal and road dust and grime
from the insert assembly. Be sure to remove and drain the hose and open the
valves before opening the low point drain lines for winterization.
HEATED FRESH WATER TANK
The Interstate motorhome has 12-Volt heat pads installed with the fresh wa-
ter and grey water holding tanks to help prevent freezing. The tank pads are
controlled by a lighted switch located on the forward shower wall just inside
the sliding door. The switch is lit when the pads are on. Battery power will last
about 4 hours unless the unit has a 120-volt source (generator or shoreline) to
operate the inverter/charger. To conserve battery power in a remote location RV
antifreeze may be used to protect the tanks in freezing conditions.
DRAIN VALVE LOCATIONS
The fresh water system has four fresh water line low point drain valves. There
is two under the galley accessed by removing the drawer and two under the
curbside lounge or bed accessed by removing the cup holders. The cup hold-
ers lift up and out of the armrest.
The fresh water tank drain valve is located on the front of the tank pan under
the motorhome.
SHUT OFF VALVES
There is one shut off valve in the motorhome. It is for the toilet and is on the
water feed line beside the toilet base.
Waterline
open
close
Drain and shut off
valve positions
