ELECTRICAL SySTEMS
H - 3
H
Circuit 3. 15 Amp, coffee maker (option)
Circuit 4. 20 Amp, goes through inverter to refrigerator receptacle, middle
roadside receptacle, entertainment center receptacles, and main TV.
Circuit 5. 20 Amp. microwave
Circuit 6. 15 Amp. GFCI, Rear, exterior, and galley receptacles.
Main: All 110 voltage flows through this breaker to the other branch circuit
breakers. Shutting off this breaker will shut down all 120-volt branch circuits
fed through the panel.
Circuit 1. Roof Air Conditioner (option): Supplies power to roof A/C when
option is installed. When no A/C is installed the 30-20 dual breaker becomes
one 30 amp breaker. Circuit 2. Water Heater: 20 amp. - Water heater power
supply when used as on 110 VAC.
Circuit 3. Coffee Maker: Supplies power to optional coffee maker.
Circuit 4. Refrigerator, middle roadside, and entertainment center recep-
tacles, and main TV: This circuit goes through the Inverter/Charger. Circuit 4
can be supplied power from the inverter if needed and is protected by a GFI
circuit breaker located on the Invertor/Charger as well as the breaker on the
panel. Check both breakers if any receptacles or appliances on Circuit 4 does
not work. Also check the middle roadside GFI receptacle and reset if needed.
This receptacle and other receptacles down stream from this GFI receptacle
will not work if the GFI is kicked out.
Circuit 5. Microwave: Microwave power supply.
Circuit 6. GFI Breaker: Supplies power to the Rear, exterior, and galley recep-
tacles.
NOTE: There are also two breakers located on the inverter/charger. One
breaker protects the charger while it is charging the batteries, the other breaker
protects circuit 4 in conjunction with the distribution panel breaker. This breaker
for circuit 4 may trip even if the inverter is off.
NOTICE: Any time Main or AC breaker is tripped, turn AC off before reset-
ting. Wait two minutes to restart AC.
