EXTERIOR
E - 5
E
Roadside Exterior Features
NOTE: This is a basic explanation of the location and function of exterior fea-
tures. More in depth explanations of certain feature’s care and maintenance is
include in this manual in other sections.
1. City Water Hook-up provides access for city water to your fresh water
system. Use ½” minimum hose for water supply.
2. Water Fill is used to fill the fresh water tank. Use only clean fresh potable
water.
3. Furnace exhaust vent should be cleaned regularly. When operating furnace,
be sure exhaust can escape into a well-ventilated area. Air coming from vent
can be hot, when parking the motorhome, be sure to have proper clearance
in venting area.
4. Exterior Shower outlet can be used on the water pump or with the city
water hook up after faucet/valve/hose assembly is inserted.
5. Utility Hatch contains the cable/satellite TV inlet, the switches for the dump
valves, macerator pump and macerator pump high pressure hose reel.
6. Electronic Ignition Water Heater Door and Vent is part of the plumbing sys-
tem. The intake vent, drain plug and exhaust vent are located inside this door.
Regular maintenance by a qualified service technician is required to keep the
water heater operating efficiently.
7. Cable/Satellite TV inlet is located inside the utility hatch and is pre-wired for
cable/satellite TV. A portable satellite dish can be connected and used in the
cable connection.
8. 110 Volt Power Cord Inlet, 30-amp service is required, power cord is stored
inside rear cargo doors in a plastic storage compartment.
9. Macerator hose reel compartment stores the electric reel holding the
pump hose and the Black Tank Flush.
10. Body kit.
11. House Battery Vent (Rear Twin Model Only) allows battery gasses from
the battery compartment located under the rear lounge to escape and fresh
air to enter.
