Airstream 2015 Flying Cloud - Measuring Hitch Ball Height

4
Floor Plans And Specications
Flying Cloud 4-5
The UBW and NCC weights listed in the Specication
Chart are for the base unit with no options and uids.
Gross Vehicular Weight Rating (GVWR): is the
maximum permissible weight of this trailer when fully
loaded. It includes all weight at the trailer axle(s) and
tongue or pin.
Unit Base Weight (UBW): is the dry weight of the base
unit without options.
Net Carrying Capacity (NCC): is equal to GVWR minus
UBW Gross Axle Weight Rating (GAWR): is the value
specied as the load carrying capacity of a single axle
system, as measured at the tire-ground interfaces.
Specication Tags
For precise cargo capacity, refer to the Cargo-Carrying
Capacity tag on the inside of the screen door. The
WEIGHT OF CARGO SHOULD NEVER EXCEED
numbers shown on the tag, which is the maximum
weight of cargo you can load and carry in your specic
trailer as built with its options.
Located on the front roadside of your trailer are the Tire
and Loading, and Vehicle Manufacturing tags.
The Tire and Loading information tag lists the Size and
Cold Ination Pressure of the tires on your vehicle, the
weight of your trailer as manufactured, and the Gross
Vehicular Weight Rating (GVWR).
The Vehicle Manufacturing tag lists the Size of tires
and wheel rims, Maximum Cold Ination pressures, the
Vehicle Identication Number (VIN), and Gross Axle
ratings (GAWR).
Measuring Hitch Ball Height
The proper height will vary according to the weight you
carry and the tires you use. However, checking the
height on your trailer is relatively easy:
1. With trailer parked on fairly level ground, measure
from ground to bottom of frame, front and rear.
2. Adjust front jack until measurements are equal.
3. Now, measure from ground to the inside top of ball
coupler. This gure is the hitch height. The hitch
ball is then usually set 1/2 to 1 in. higher, according
to the spring rate of your tow vehicle, to allow for it
to settle when the trailer is hitched up.
Tire Size with Maximum Ination Pressure
Cold
• ST 215-75 R14 - 50 psi
• ST 225-75 R15 - 65 psi
