Maintenance
9-4 2022 Interstate 24X
Replacement Rivets
Interior
Part Number 330127-05 330149
Rivet Name AD45ABS ADS46ABSR
Head Style Dome Head Dome Head
Body
Diameter
(Inches)
0�125 (1/8) 0�125 (1/8)
Hole Size 0�129-0�133 0�129-0�133
Drill Number 30 30
Grip Range In
(Inches)
0�251-�312 0�125-0�375
Length Under
Head (Max�
Inches)
0�453 0�960
Head
Diameter
(Nominal)
0�250 0�312
Head Height
(Max� Inches)
0�040 0�060
Typical Sheer
Strength (lb)*
155 150
Typical Tensile
Strength (lb)*
235 150
*Values shown are a guide only and may vary
depending upon the application�
Exterior Care
The following exterior care products are recommended
by Airstream� Read and follow label directions� Exterior
sealant should be checked and resealed once a year�
Walbernize Super Seal (PN - 28433W) - Use to clean
and polish while depositing a reective, water-proof,
glaze nish. Recommend two applications a year.
Acryl-R Seam Sealer (PN - 28430W-01 [16 oz can-
Gray]) - Use anywhere a ne bead of gray sealant is
required�
Acryl-R Seam Sealer (PN - 28430W-04 [16 oz can-
White]) - Use anywhere a ne bead of White sealant is
required�
Acryl-R Seam Sealer (PN - 28430W-06 [16 oz can-
Clear]) - Use anywhere a ne bead of Clear sealant is
required�
AdSeal Premium Quality Sealant Adhesive (PN
- 365330-01 [10 oz tube-White]) - Use anywhere a
thicker bead of White sealant is required�
AdSeal Premium Quality Sealant Adhesive (PN
- 365330-02 [10 oz tube-Gray]) - Use anywhere a
thicker bead of Gray sealant is required�
AdSeal Premium Quality Sealant Adhesive (PN
- 365330-03 [10 oz tube-Aluminum Gray]) - Use
anywhere a thicker bead of Aluminum Gray sealant is
required�
AdSeal Premium Quality Sealant Adhesive (PN
- 365330-04 [10 oz tube-Black]) - Use anywhere a
thicker bead of Black sealant is required�
Touch-up Caulking
Caulk, Acrylic, Silver PN – 360396
Mercedes Sprinter Touch-up Paint Codes
Iridium Silver 9775
NOTE
*Paint codes, along with weight ratings, can be
found on a sticker attached to the drivers seat
pedestal.
