13-2
EXPLODED VIEWS AND SPARE PARTS LISTS
SM SX DCI 1-A.3 GB
13.2 Indoor Unit: SX 9, 12 DCI
No Part No Description Qty
1 307979 Back panel 1
2 382334 Base panel EPS 1
3 452731900 Evap. Assy SX25/35 1
4 373247 Fan frame 1
5 455000600 Capacitor SX25/35 1
6 323425 Motor support 1
7 293321 Centrifugal fan 2
8 452987400 Transformer for SX25/35 1
9 4520158 Motor SX25/35 1
10 4521029 Spring clip 2
11 372341 Fan cover 2
12 373245 Left panel 1
13 221555 Filter 2
14 307981 Front panel 1
15 484001 Air inlet assy 1
16 4525333 Motor connect wire for SX25/35 1
17 373244 Right panel 1
18 371257 Vertical louver 10
19 370281 Air outlet 1
20
375209-01 AIRWELL Display panel 1
375209-05 WESPER Display panel 1
375209-16 ELECTRA Display panel 1
375209-17 JOHNSON Display panel 1
4521827 GORENJEN Display panel 1
4521831 FAGOR Display panel 1
21
372338 Horizontal louver front 1
372339 Horizontal louver back 1
22 263034 Swing motor 1
23 436665 Stop motor 1
24 391508 Connect wire 1
25 234213 Display 1
26
391725 Power cord without plug 1
4521070 Power cord (European plug) 1
27 438413 Room sensor 1
28 438082 Coil sensor 1
29 452935900 DCI STORM 1
30 311036 Storm panel 1
