EXPLODED VIEWS AND SPARE PARTS LISTS
SM SX DCI 1-A.3 GB
13.4 Indoor Unit: SX 18 DCI
No Part No Description Qty
1 307980 Back panel 1
2 382333 Base panel EPS 1
3 4527244 Evap. Assy SX18 1
4 373246 Fan frame 1
5 455000604 Capacitor SX18 1
6 453206900 Transformer 1
7 323422 Motor support 1
8 293322 Centrifugal fan 2
9 4520931 Motor Assy SX18,24 1
10 4521029 Spring clip 2
11 4525333 Motor connect wire 1
12 372340 Fan cover 2
13 373245 Left panel 1
14 221554 Filter 2
15 307982 Front panel 1
16 484002 Air inlet assy 1
17 373244 Right panel 1
18 371257 Vertical louver 12
19 370280 Air outlet 1
20 375209-16 ELECTRA Display panel 1
21
372336 Horizontal louver front 1
372337 Horizontal louver back 1
22 263034 Swing motor 1
23 436665 Step motor 1
24 391508 Connect wire 1
25 234213 Display 1
26 391726 Power cord 3x2.5 1
27 438082 Coil sensor 1
28 438413 Room sensor 1
29 452935900 DCI storm 1
30 311036 Storm panel 1
