EXPLODED VIEWS AND SPARE PARTS LISTS
SM SX DCI 1-A.3 GB
13.11 Outdoor Unit: GC 24, 30 DCI
No. Part No. Description Unit
1 465100000 Outlet grid 1
2 4523652 PAINTED LEFT CABINET ASSY 1
3 4523758 Nut M8 left 1
4 452960400 OUTDOOR FAN 1
5 461600002 4-Way Valve Assy. 1
6 452956700 4-way valve coil 1
7 4526522 Four-Way Valve R410A 1
8 452855600 DC Resin Motor(EHD80A90EC/SIC-71FW-F170-1) 1
9 4522601 Right Handle 1
10 4523653 Painted Right Cabinet Assy. 1
11 452966200 Compressor Top Thermistor(CTT) 1
12 452956500 Suction Thermistor(SUCT) 1
13 452677601 Outdoor Coil Thermistor(OCT) 1
14 452809900 Base Plate Painting Assy. 1
15 452803300 Compressor Assy. TNB220FLBM1 1
16 452783600 Oil Separator Assy. 1
17 452783200 Liquid-Gas Separator 1
18 453256100 Support Painting Assy./Gas-Liquid Separator 1
19 4526080 Valve Plate Paint Assy. 1
20 4526513 Low Press Valve R410A 1
21 4526514 High Press Valve R410A 1
22 4523654 Painted Right Back Cabinet Assy. 1
23 4522602 Valve Cover 1
24 4518950 Filter Drier BFK-053S 1
25 467300005 Display Assy.(optional) 1
26 204107 Cable clip Nylon 2
27 467420003 7 Poles Terminal Block 1
28 453138800 Terminal Plate 1
29 4526215 Electronic Expansion Valve ZDPF(L)-1.6C-01-RK 1
30 4526216 EEV COIL QA(L)12-MD-02 1
31 462300002 Condenser Assy. 1
32 453175500 Guard Net Painting Assy. 1
33 453083800 OAT Support 1
34 453256000 Choke Assy. 1
35 452809700 Partition Plate 1
36 453170000 Controller 1
37 452888500 Motor Support 1
38 464250004 Controller Connect Plate 1
39 4526968 Grounding wire with magnetic ring 1
40 4526774 Outdoor Air Thermistor(OAT) 1
41 4523657 Painted Top Cover Assy. 1
42 4522600 Left Handle 1
