Airwell GC 24 RCC-S - Electrical Connection Specifications; Wiring for Cooling and Heatpump Modes

5
* IMPORTANT: Cables should be sized depending on regulations in force:
they depend on the mode of installation and type of wires.
ELECTRICAL CONNECTION SPECIFICATION
S
INDOOR DS 16 RCG
OUTDOOR GC 16 RCC
Power supply 1/230V/50Hz *
COOLING+VENTILATION
Main power supply cable section* 3CORES 3CORES 5CORES 3CORES 5CORES
Cable section between units* 6CORES 6CORES 6CORES 6CORES 6CORES
DEHUMIDIFICATION MODE
(COOLING+VENTILATION+REVERSE
CYCLE)
Main power supply cable section* 3CORES 3CORES 5CORES 3CORES 5CORES
Cable section between units* 6CORES 6CORES 6CORES 6CORES 8CORES
DS 18 RCG
GC 18 RCC-S
*
DS 24 RCG
GC 24 RCC-S
*
STANDARD / HEATPUMP
DS MAN. MENU
