Exploded View and Spare Part list
Light Commercial 43
Spare part list of indoor unit: JOSI-DCD012-N11
No.
BOM Code
Part Name
Quantity
1
201285190014
Chassis assembly
1
2
201185190001
Up volute shell
2
3
201100100809
Centrifugal fan
2
4
201185190002
Below volute shell
2
5
201280200005
Fan motor axes clamp (left)
1
6
201252490002
Fan motor fixing board
1
7
201280200006
Fan motor axes clamp (right)
1
8
202400300053
Asynchronous motor
1
9
201252290005
Supporter of fan motor
1
10
201285190002
Middle beam assembly
1
11
201270290091
Left clapboard assembly
1
11.1
201270890021
Hook
2
12
201552290012
Evaporator assembly
1
12.2
201652290013
Output pipe assembly
1
12.3
201600320001
Copper nut
1
12.4
201670190020
Input pipe assembly
1
12.4.1
201600320000
Copper nut
1
13
201270290034
Evaporator right support board assembly
1
14
202440500004
Pipe temperature sensor assembly
1
15
202285190003
Water collector
1
16
201270290090
Right clapboard assembly
1
16.1
201270890021
Hook
2
17
203370190015
Electronic control box assembly
1
17.1
201270290163
Electronic control box
1
17.3
202301450003
Wire joint
1
17.6
202301310075
Ambient temperature sensor assembly
1
17.7
201352290020
Main control board assembly
1
18
201270290081
Cover of electronic control box
1
19
201270290082
Pipe clamp board assembly
1
20
2033702A0077
Display box assembly
1
20.1
201370290012
Display board assembly
1
21
17317100A07946
Wired controller
1
22
201285190003
Rear beam
1
23
201285190004
Rear cover assembly
1
24
201285190008
Top cover assembly
1
