Airwell johnson Multi Splits Series User Manual

Exploded View and Spare Part list
Light Commercial 45
Spare part list of indoor unit:JOSI-DAQ012-N11
No.
BOM Code
Part Name
Quantity
1
2011440A0001
Panel assembly
1
2
201144090002
Air filter
1
3
201144090022
Panel frame assembly
1
4
201544090014
Evaporator assembly
1
4.1
202301310085
Pipe temperature sensor assembly
1
5
201144090030
Ventilation assembly
1
6
201144090016
Chassis assembly
1
6.1
201244090009
Hang board assembly
1
7
201131410703
Anti-bacterial filter
2
8
201132200713
Bracket of air filter
2
9
2033440A0034
Electronic control box assembly
1
9.1
201144090009
Installation plate of electric parts I
1
9.2
201144090010
Electrical control box
1
9.3
201244090003
Fixing board of electronic control box II
1
9.4
202301310072
Ambient temperature sensor assembly
1
9.5
202301400072
Wire joint
1
9.7
201244090002
Electronic control box seal plate
1
9.8
201144090008
Installation plate of electric parts
1
9.9
201344090004
Display board assembly
1
9.10
2013440A0029
Main control board assembly
1
9.11
201244090004
Fixing board of electronic control box I
1
9.14
201344090029
Auxiliary electric heater control board
1
10
201144090044
Water collector
1
10.1
202400200052
Louver motor
1
10.2
P0000281380
Underside louver
1
11
201144090042
Air outlet assembly
1
11.1
202400200053
Louver motor
1
11.2
201244090008
Rear net
1
11.3
P0000283050
Up louver
1
13
201144090011
Pipe clamp
1
14
201244290015
Installation clamp
2
15
17317000A15640
Remote controller
1
17
201144090005
Insulation washer
1
18
201244090001
Cover of electronic control box
1
19
201100100020
Centrifugal fan
1
20
202400300014
Fan motor
1
21
201244090005
Supporter assembly of fan motor
1
