CONTROL LIGHTS AND CONTROL
BUTTONS ON THE AIR CONDITIONER
A
Standby light (Stby)
Lights up when the air conditioner
is connected to the power source
and ready to receive commands
from the remote control
B
Operation Lights (Oper)
Lights up when the air conditioner
is operating. One flicker indicates
that the signaling of the remote
control has been received and
stored. Continuous flickering
indicates that the compressor is in
protection mode.
C
Timer Light (Timer)
Lights up when the air conditioner
is set to Timer or Sleep mode.
D
Filter Light (Filter)
Lights up when the air filter needs
cleaning.
E
Cooling Light (Cool)
Lights up when the “F” (Mode)
Button is pushed. Manual Cool
Operation
F
Operating mode button –
Cooling/Heating operation
Used for switching the air
conditioner OFF or ON in COOL
or HEAT mode, without using the
remote control.
G
Heating Light (Heat)
Lights up only when the “F”
(Mode) button is pressed.
Manual Heat Operation.
H
Filter reset/stop button
- Used for turning off the filter
light and resetting the count of
operation hours of the air
conditioner, after the clean
filter has been restored to its
place.
- Used for cancelling the
operation of the buzzer if so
desired.
I
Signal receiver
The place to which the remote
control device should be pointed.
