9.Rear support leg (optional)
9-4
Rear support
Install the rear support: press and hold the rear support button (Figure 9-1), insert the rear support into the reserved
hole (Figure 9-1), and release the rear support button after clamping, the installation is complete; Disassembly rear
support: Press and hold the rear support button and pull out the support at the same time.
Note: When the rear support wheel is installed downwards, it can be used as an anti-roll wheel (Figure 9-3); when the
rear support wheel is installed upwards (Figure 9-2), it can be used as a rear support. See the nal use of the foot (Figure
9-4).
Rear support button
Reserved hole
Anti-roll wheel
Rear support
9-1 9-2
9-3
