Description ......................................... 5
Installation........................................22
Start-Up.............................................39
Troubleshooting..............................41
Parts List ..........................................44
Maintenance ....................................47
Warranty ...........................................48
ComPac
®
I and ComPac
®
II
Air Conditioner Product Manual
Vertical Wall-Mount Air Conditioners
with Front Control Box Panel
Models AVP20-24-30-36-42-48-60-72
P/81024 9/04-12
supersedes 11/03-11
Manufactured By:
Marvair
®
Division of AIRXCEL
®
, Inc.
P.O. Box 400 • Cordele, Georgia 31010
156 Seedling Drive • Cordele, Georgia 31015
(229) 273-3636 • Fax (229) 273-5154
E-mail: marvairtech@airxcel.com • Internet: www.marvair.com
